AGFA CR-12-X Digitizer CR Machine

New

0.0|0 Ratings

Quantity :

Specifications

Product Type : Computed Radiography (CR) Digitizer
Feed Type : Single Cassette Feed
Throughput : Up to 44 plates/hour
Greyscale Resolution : 20-bit acquisition / 16-bit output
Display : LED Status Indicator
Status/Error : Display External PC Monitor
Dimensions (W × D × H) : 580 × 700 × 471 mm
Depth without Cassette Unit : 380 mm
Weight : 31 kg
Power Supply : Autoranging external power supply
Input Voltage : 100 – 240 V
Current : < 2 A
Frequency : 50/60 Hz
Noise Level : Max. 65 dB(A)
Heat Dissipation : Standby 30 W / Max. 108 W
Operating Temperature : 15°C – 35°C
Operating Humidity : 10% – 75% RH
Transport Temperature : 5°C – 40°C
Mobile Use : Yes
Compliance : CE, cNRTLus
Software Compatibility : NX Workstation / MUSICA™
Applications : General Radiography, Ortho, Chiro, Full Leg/Spine
Connectivity : DICOM / Network integration

highlights

Affordable entry-level digital radiography solution
Allows users to choose between faster workflow or higher resolution
High throughput with customizable workflow
Automated calibration and image processing
Easy integration with NX Workstation
Easy replacement of covers, modules, and parts using a single tool
Minimal intervention due to only two motors in cassette handling system
Proven Agfa HealthCare imaging technology with low total cost of ownership

in the box

AGFA CR 12-X Digitizer unit
NX / MUSICA® Workstation software
External power supply
USB smartcard / service card
Cassette adapter(s) (depending on package)
User manuals / installation guide
Required cables and accessories

Use Cases :

General Radiography
Orthopedic Imaging
Chiropractic Imaging
Full Leg / Full Spine applications
Clinics and private practices upgrading from film-based X-ray
Mobile imaging facilities and outreach units
Hospitals with limited workspace

Key Features :

Compact tabletop design ideal for space-restricted environments
Single cassette feed mechanism for easy operation
Adjustable speed vs. resolution settings per study
Up to 44 plates/hour throughput (depending on cassette size and resolution)
MUSICA™ image processing for automatic image optimization
SmartRotate™ AI automatically orients images correctly
20-bit data acquisition for high-detail capture
16-bit output to processor (square root compressed)
DICOM compliant for seamless integration
Supports mobile installations in vans, trucks, and mobile clinics
Low maintenance modular design with easy service access
USB smartcard technology for service and site-specific settings storage

Warranty

Seller

AA MEDIE QUIPLearn More

Product Description

The AGFA CR 12-X is an affordable, compact Computed Radiography (CR) digitizer designed for clinics, hospitals, orthopedic centers, and private practices transitioning from film to digital radiography. This tabletop system offers a balance of high image quality, adjustable speed, and user-controlled...
