Fresenius 5008s Dialysis Machine

New

Specifications

Product Name : Fresenius 5008S Dialysis Machine
Display : 15-inch TFT color touchscreen (rotatable)
Dimensions (H × W × D) : Approx. 1680 × 350 × 780 mm
Weight : Approx. 114 kg
Power Supply : 100 – 240 V AC ±10%
Frequency : 50 – 60 Hz
Current Consumption : Approx. 6 A at 230 V
Dialysis Modalities : Hemodialysis (HD), Online Hemodiafiltration (HDF)
Blood Pump Flow Rate : Up to ~600 mL/min (model dependent)
Dialysate Flow Rate : Typically up to ~800 mL/min
Ultrafiltration Control : Volumetric UF control
Water Inlet Pressure : 1.5 – 6.0 bar
Water Temperature : 5 – 30 °C
Maximum Drain Height : 1 m
Data Connectivity : LAN (RJ45) for Therapy Data Management System
Safety Systems : Venous Access Monitoring (VAM), air detection, blood leak monitoring
Disinfection : Automatic heat disinfection programs
Optional Modules : Blood Pressure Monitor (BPM), Blood Volume Monitor (BVM), Blood Temperature Monitor (BTM)

highlights

Advanced HighVolumeHDF therapy enabling improved toxin removal.
Automated substitution control with AutoSub Plus for optimal therapy.
Real-time dialysis dose monitoring (OCM) to ensure treatment adequacy.
Integrated safety monitoring including VAM for venous access protection.
Eco-efficient operation with reduced dialysate, water, and energy consumption.
Online priming and reinfusion eliminating the need for saline bags.
Flexible therapy modes including HD and HDF with customizable treatment profiles.

in the box

Fresenius 5008S Dialysis Machine (Main Unit)
Rotatable touchscreen monitor
Blood pump module
Dialysate mixing and delivery system
Bicarbonate cartridge holder (Bibag system)
Power cable and connection cables
Operator/User manual
Installation and maintenance documentation
Optional monitoring modules (depending on configuration)

Use Cases :

Hospital dialysis units
Specialized nephrology departments
Standalone dialysis centers
High-volume hemodiafiltration therapy
Chronic kidney disease (CKD) maintenance dialysis
Acute kidney injury (AKI) dialysis treatment
Clinical dialysis research and advanced renal therapy programs

Key Features :

HighVolume Online Hemodiafiltration (HDF) capability as a standard therapy option.
AutoSub Plus Technology automatically optimizes substitution volumes during HDF treatment.
Online Clearance Monitor (OCM) for real-time dialysis dose monitoring (Kt/V).
Venous Access Monitor (VAM) for early detection of venous needle dislodgement.
ONLINEplus technology produces sterile substitution fluid directly during treatment.
AutoFlow system automatically adjusts dialysate flow rate according to blood flow.
EcoFlow technology reduces water, dialysate, and energy consumption.
Large rotatable touchscreen display for simplified monitoring and control.
Optional monitoring modules such as Blood Pressure Monitor (BPM), Blood Volume Monitor (BVM), and Blood Temperature Monitor (BTM).
Network connectivity and data management system for treatment documentation.

Warranty

Seller

AA MEDIE QUIPLearn More

Product Description

The Fresenius 5008S Hemodialysis System is an advanced dialysis machine designed for efficient renal replacement therapy in patients with kidney failure. It is engineered to perform hemodialysis (HD) and online hemodiafiltration (HDF) treatments with high precision and automation. The system integra...
