3 Channel ECG Machines Online at Best Prices in India

The 3-Channel ECG Machine is a crucial heart diagnostic device used in healthcare facilities— bridging affordability, clinical reliability, and portability. It is able to record the heart electrical activity from the all 12 standard lead with simultaneous 3 channel Output, this machine presented in 3×4 or sequential print formats. 3 channel ECG machine is good for routine heart monitoring, small clinics, dispensary, mobile healthcare system, etc.

<strong>Main Insight:</strong>

12-lead acquisition system (standard limb and precordial leads),
Simultaneous 3-channel recording and printing,
Digital filtering and signal processing for clearer waveforms.

Key-feature which make 3 Channel ECG Machine Unique

This machine comes with following unique features:

Clear & Quick Output

You will get 3 channel simultaneous printout report
Thermal or high-resolution printing option available with adjustable speed and sensitivity options.
When need the continuous monitoring you can use rhythm mode

Digital Connectivity & Storage

Built-in memory option available for storing ECG records
You can transfer, archiving, and integration data with hospital system via USB/PC connectivity

Power & Portability

In machine rechargeable batteries feature available for remote monitoring or bed-side use
For mobility within facility design lightweight and compact body

Clinical Uses & Benefits

<a href="https://www.equipmedy.com/ecg-machine" target="_blank">ECG machine</a> not just device, they’re critical decision-support systems for cardiac care:

Effective for Early Detection and Monitoring:

This machine helps to detect arrhythmias, ischemia, heart blocks, and electrolyte imbalance risks.
Also used for pre-operative measurement to ensure patient safety

Ideal for Routine and Emergency Care:

This is best option for routine heart check-ups
You can use this for continuous monitoring in hospital and cardiology department
Excellent for Emergency diagnostics due to quick acquisition and print-out turnaround

Better Workflow & Patient handling:

Increase patient output with auto-interpretation and print preview features
Enables digital record keeping for longitudinal patient care
Facilities telemedicine workflows when connected with PC software

What to Consider Before Buying 3 Channel ECG Machine?

To choose the right 3-Channel ECG machine, consider following things:

Performance Specs

Sampling rate (typically 500–1000 Hz) — higher rates give finer detail.
Frequency response and filter quality — to reduce noise and motion artifact.

Display & Print Flexibility

For better preview consider clarity and size of Display
Multiple print speed settings and format options

Data Storage & Integration

For the futures reference choose on-board memory capacity and PC transferable formats
Compatibility with clinic/hospital EMR systems

Safety & Regulatory Compliance

Patient safety standards (Type CF protection, defibrillation safe)
Warranty, service availability, and compliance with local medical device regulations

3 Channel ECG Machine Price in India

When you go online to buy a 3-channel ECG machine, you will see a price range of ₹22,000 – ₹68,000 in India.

A 3-channel ECG machine with automatic measurement and interpretation, a high sampling rate, and leading brands will cost you more.

Features/Specification	BPL GenX3is	Contec 300GA	RMS Vesta 301i
Channel	3-channel simultaneous ECG (12-lead)	3-channel simultaneous ECG (12-lead)	3-channel simultaneous ECG (12-lead)
Display	4.3″ TFT colour display	3.5″ TFT colour display	3.5″ TFT colour display
Sampling Rate	1000 Hz sampling frequency	1000 Hz sampling frequency	Standard clinical sampling
AD Converter	12-bit A/D converter	12-bit A/D converter	Typical 12-bit resolution
Display Preview/ Keyboard	Numeric keypad controls	Standard function keys	Full alphanumeric keyboard for data entry
Storage Capacity	250 ECGs internal (approx)	1000 ECG records	Stores up to 20 patient ECGs internally
Recording Modes	Auto & Manual modes	Auto, Rhythm, Manual modes	Auto & Manual recording with multiple print modes
Printing System	In-built thermal printer (80 mm)	Thermal printing system (80 mm)	Thermal array printer with multiple print formats
Filters & Noise Reduction	Baseline & low pass filters	AC, baseline, EMG filters	Digital filters for baseline drift, AC & EMG interference
Connectivity	USB connectivity	USB/PC interface available	USB interface with optional PC connection & A4 printing
Battery	Rechargeable battery pack	Li-Ion rechargeable battery	Li-Ion rechargeable battery (11.1 V / 2600 mAh)
Weight	2 kg portable	1.8–2.25 kg compact	1.8 kg lightweight
Dimensions	Standard portable size	Standard portable size	288 × 238 × 85 mm
Defibrillator Protection	Yes (standard safety)	Yes (Class I, Type CF)	Yes (isolation protection)
Typical Usage	Hospitals, clinics, bedside & routine use	Hospitals, clinics, diagnostic centers	Hospitals, clinics, diagnostic centers
Warranty	1 year standard warranty	1 year standard warranty	1 year manufacturer warranty
