Arphi Proton SX5 Digital Portable Audiometer

New

₹86,500₹100,00014% off

Specifications

Model : Proton SX5 Digital Portable Audiometer
Type : Diagnostic Digital Portable Audiometer
Test Types : AC, BC, Tone Decay, Speech, SISI special test
Input Options :Tone, Speech, Tape/CD, Pulse tone
Output Channels : Left, Right, Bone L+R, Free Field L/R/Both
Noise Masking : Wideband, Narrowband
Display : LED backlit LCD (155 × 16 mm), 2×16 char
Accuracy : Frequency ±2%; Electrical hearing level ±1 dB; Acoustical ±3 dB
Distortion : <1% THD
Connectivity : USB (for PC software)
Power Supply : 230 V AC, 50 Hz
Dimensions : 275 × 200 × 80 mm
Weight : Approx. 1.7 kg
Grade : Medical Grade

highlights

Advanced Digital Technology: Ensures reliable and precise audiometric testing across frequencies.
Data Management: PC connectivity enables efficient management of patient test records.
Multi-channel Outputs: Supports separate stimulus and masking channels.
Ergonomic Controls: Simple menu-driven operation speeds up the testing process.

in the box

Arphi Proton SX5 Digital Portable Audiometer unit
Audiometry headphones for air conduction testing
Bone conduction transducer with adjustable headband
Patient response hand switch
Power supply cable
User manual / documentation
Dust cover / protective cover
Optional PC connectivity cable/software (for SX5 versions)

Use Cases :

Routine hearing assessment in hospitals and ENT clinics.
Diagnostic audiometry by audiologists and hearing specialists.
Mobile and community hearing screening camps due to its portable design.
Occupational health programs for monitoring employees’ hearing.
Hearing aid centers to evaluate hearing before and after fittings.

Key Features :

Comprehensive Test Support: Air Conduction (AC), Bone Conduction (BC), Tone Decay, Speech Audiometry, and SISI (Short Increment Sensitivity Index) special test.
Wide Noise Masking Options: Includes wideband and narrowband masking noise for accurate threshold measurement.
Input/Output Options: Accepts tone, speech, tape/CD, and pulse tone inputs; produces outputs for left/right ears, bone conduction, and free field.
User-Friendly Display: LED backlit LCD display (155 × 16 mm) with clear readings under varied lighting conditions.
Portable & Lightweight: Compact form factor and ergonomic design make it easy to transport between clinics or for field screening.
USB Connectivity: Allows connection to a computer for saving, reviewing, editing, and printing audiograms.

Warranty

Seller

AA MEDIE QUIPLearn More

Product Description

The Arphi Proton SX5 Digital Portable Audiometer is a medical-grade, fully digital diagnostic audiometer designed for accurate assessment of hearing function. It supports comprehensive audiometric tests including air and bone conduction, speech audiometry, tone decay, and special tests (e.g., SISI)....
