ABM 12I 12 Channel ECG Machine

New

4.5

12456 Ratings

₹62,000₹90,00031% off

Specifications

Product Name : ABM 12I 12 Channel ECG Machine
ECG Channels : 12 Channel (Simultaneous)
Lead System : Standard 12-Lead
Display : Color TFT / LCD Display
Recording Method : Thermal Printing
Print Width : 210 mm
Paper Speed : 25 mm/s, 50 mm/s
Sensitivity : 2.5, 5, 10, 20 mm/mV
Frequency Response : 0.05 – 150 Hz
Input Impedance : ≥ 50 MΩ
CMRR : ≥ 100 dB
Heart Rate Measurement Range : 30 – 300 bpm
Operating Modes : Auto / Manual
Interpretation : Automatic ECG Analysis
Noise Level : ≤ 15 μVp-p
Data Storage : Internal Memory
Connectivity : USB / LAN (model dependent)
Power Supply : AC 110–240 V, 50/60 Hz
Battery Rechargeable : Li-ion / SLA
Battery Backup : Approx. 3–4 hours
Safety Standard : IEC / CE compliant
Portability : Desktop / Portable
Weight (Approx.) : 4 – 6 kg
Warranty : Typically 1 Year

highlights

True 12-lead, 12-channel simultaneous printing
Faster diagnosis with automatic interpretation
Large, clear display improves waveform visibility
Portable with battery backup for bedside use
Ideal for high patient-volume environments

in the box

ABM 12I 12 Channel ECG Machine
10-Lead Patient Cable
Limb Electrodes (4 Nos.)
Chest Electrodes (6 Nos.)
ECG Thermal Paper (210 mm or compatible)
Built-in Rechargeable Battery
Power Cord
User Manual

Use Cases :

Cardiology departments
Multi-specialty hospitals
Diagnostic & pathology centers
Emergency rooms and ICUs
Pre-operative and routine cardiac screening
Mobile cardiac camps and health check-ups

Key Features :

12-channel simultaneous ECG acquisition and printing
High-resolution color TFT/LCD display for real-time waveform preview
Built-in thermal printer with wide paper support
Automatic ECG interpretation and measurements
Auto & manual operating modes
Rechargeable internal battery for uninterrupted use
Internal memory for ECG data storage
USB / LAN connectivity (model dependent)
Low noise, high signal accuracy
User-friendly keypad/interface

Warranty

Seller

AA MEDIE QUIPLearn More

Product Description

The ABM 12I 12 Channel ECG Machine is a high-performance electrocardiograph designed to record and print all 12 ECG leads simultaneously, delivering fast, accurate, and detailed cardiac assessments. Equipped with a large color display, built-in thermal printer, rechargeable battery, and advanced ana...
