Shipping time and rates
Shipping about 5-7 days
BPL Cardiac Stress Test System TMT Machine-(Dynatrac Ultra)
New0.0|0 Ratings
Quantity :
1
Specifications
- Product Name : BPL Dynatrac Ultra Cardiac Stress Test System
- Brand : BPL
- Model : Dynatrac Ultra
- ECG Leads : 12-lead simultaneous acquisition
- Sampling Rate : 1000 samples/sec (wired), 500 samples/sec (wireless)
- ECG Analysis Rate : 200 samples/sec
- Resolution : 16-bit
- Frequency Response : 0.5 – 100 Hz
- CMRR : ≥ 90 dB
- Input Dynamic Range : ±10 mV
- Patient Leakage Current : <10 µA
- Protocols : Bruce, Modified Bruce, Naughton, Balke, Custom
- Parameters Measured : ST level, ST slope, HR, METS
- Display Resolution : 1024 × 768 pixels
- ECG Display : 3 / 6 / 12 lead formats
- Sweep Speed : 25 mm/sec, 50 mm/sec
- Filter Options : 20 Hz / 40 Hz selectable + 50 Hz notch
- Connectivity : USB / Wireless (optional)
- Software : Windows-based TMT software
- Treadmill Speed : 0 – 30 km/h
- Inclination : 0 – 26%
- Max Patient Weight : Up to 180 kg
- Walking Area : 1580 × 480 mm
- Machine Dimensions : ~197 × 73 × 130 cm
- Weight : ~129 kg
- Power Requirement : 200–240V AC, 50 Hz
- Safety : Defibrillator protection, emergency stop, lead-off alerts
- Operating Temperature : 10°C – 40°C
- Humidity : 20 – 90% non-condensing
highlights
- High diagnostic accuracy with real-time ECG + ST analysis
- Automatic BP measurement during each test stage
- Robust treadmill design for continuous hospital usage
- Advanced artifact filtering ensures noise-free signals
- Seamless workflow with automated reporting
- Reliable Indian brand with easy service & support
- Integration-ready with hospital IT systems (DICOM/HL7 compatible)
in the box
- Dynatrac Ultra TMT Software
- ECG Acquisition Module (wired/wireless option)
- 12-lead ECG cable & electrodes
- Medical-grade treadmill unit
- Patient safety harness
- Power cables & connectors
- User manual & documentation
Use Cases :
- Detection of coronary artery disease (CAD)
- Exercise stress testing (TMT) in cardiology departments
- Arrhythmia and ischemia diagnosis
- Pre-operative cardiac evaluation
- Cardiac rehabilitation monitoring
- Preventive cardiac screening programs
- High-volume hospital OPD diagnostics
Key Features :
- 12-lead ECG monitoring with real-time display
- Advanced noise filters (EMG, baseline drift, AC interference)
- Windows-based smart stress test software
- Programmable protocols: Bruce, Modified Bruce, Naughton, Balke & custom
- Automatic BP monitoring during stress test (optional)
- Arrhythmia detection & ST-segment analysis
- Heart rate recovery analysis
- USB-based ECG acquisition & PC connectivity
- Lead-off detection with safety alerts
- User-defined reporting with trend charts
- Compatible with hospital EMR systems
Warranty
Seller
AA MEDIE QUIPLearn More
Product Description
The BPL Medical Technologies Dynatrac Ultra TMT System is a premium computerized cardiac stress testing solution designed for accurate detection of coronary artery disease and exercise-induced cardiac abnormalities.
It integrates a 12-lead ECG acquisition system with a medical-grade treadmill, deli...
