Contec TLC 9803 Holter ECG System (3-Channel)

New

4.5

12456 Ratings

₹32,700₹45,00027% off

Specifications

Model : TLC9803 Holter ECG System
Channels : 3-channel ECG (three leads)
Recording Duration : Up to 24 hours continuous
Sampling Rate : 10,000 Hz
Resolution : 12-bit
Scale Voltage : 1 mV ± 5 %
Sensitivity : 10 mm/mV ± 5 %
Noise Level : ≤ 30 µV
CMRR : ≥ 60 dB
Low-Frequency Time Constant : > 3.2 s
Scan Speed : 25 mm/s ± 5 %
Enduring Polarization Voltage : ±300 mV
Min. Measurable Signal : 50 µV p-p
Interface : USB 2.0
Power Supply : 2 × AA batteries
Safety Type : Type B (Internally powered)
Dimensions : ≈ 111 × 60 × 25 mm
Weight : ~102–105 g (without batteries)

highlights

Continuous 24-hour capture: Ensures transient arrhythmias and events are recorded during daily activities.
Advanced analytic tools: Built-in arrhythmia templates and variability metrics help clinicians interpret data efficiently.
USB data transfer: Fast and easy integration with PC software for review, editing, and reporting.
Portable & convenient: Lightweight design with battery operation makes it suitable for both clinical and outpatient monitoring.
Reliable signal quality: High CMRR, low noise, and detailed sampling improve diagnostic confidence.

in the box

CONTEC TLC9803 3-Channel Holter ECG Monitor (main recorder)
ECG Lead Cable Set (3-lead)
ECG Disposable Electrodes
USB 2.0 Cable for PC connectivity
Storage Bag or Pouch
User Manual (and quick-start guide)
Analysis Software (usually downloadable from official source)
AA Batteries (2) included in some packages

Use Cases :

Ambulatory Cardiac Monitoring: Detect arrhythmias not seen on short ECGs by recording over 24 hours.
Post-Symptom Evaluation: Correlate recorded ECG patterns with patient symptoms (e.g., palpitations, dizziness).
Pacemaker Function Monitoring: Analyze pacemaker activity and pacing rhythms.
Heart Rate Variability (HRV) and Comprehensive Analysis: Support deeper assessment of autonomic function and cardiac risk factors.
General Clinical Diagnostics: Assist in diagnosing atrial fibrillation, ventricular premature beats, conduction abnormalities, and more.

Key Features :

3-Channel ECG Recording: Simultaneous capture of three leads for comprehensive rhythm monitoring over extended periods.
24-Hour Continuous Monitoring: Stores ECG data in real time for a full day to catch intermittent events.
High Sampling Rate: Up to 10,000 Hz with 12-bit accuracy for detailed waveform capture.
USB 2.0 Connectivity: Easy transfer of recorded data to a computer for analysis and reporting.
Advanced Analysis Software: Supports arrhythmia templates (e.g., atrial/ventricular beats, pauses, fibrillation), heart rate variability, and pacemaker analysis.
Compact & Lightweight: Portable design suitable for ambulatory applications.
Battery Powered: Operates using two standard AA batteries, making it convenient for outpatient use.

Warranty

Seller

AA MEDIE QUIPLearn More

Product Description

The CONTEC TLC9803 Holter ECG System is a portable 3-lead ambulatory cardiac monitoring device that records continuous ECG data over a 24-hour period to help clinicians detect transient arrhythmias and other cardiac abnormalities that might not show up during a short standard ECG test. Its compact d...
