RMS VEGA 204 AC TMT Treadmill Test System

New

0.0|0 Ratings

Quantity :

Specifications

Acquisition : Simultaneous 12 leads, 14-bit
Sampling Rate : 3600 samples/sec
Input Impedance : >100 MΩ
Time Constant : 3.2 sec
CMRR : >100 dB
Patient Leakage Current : <10 µA
Frequency Response : 0.05 – 100 Hz
Digital Filters : 0.05 – 100 Hz
Baseline Correction : DSP-based
Sweep Speed : 5, 12.5, 25, 50, 100 mm/sec
Sensitivity : 0.25, 0.5, 1, 2, 4 cm/mV
Calculated Parameters : ST level, ST slope, HR, METS, Axis
HR Computation : Based on 6 beats, updated every second
Display : 1024 × 768 pixels
Printer : Laser / Deskjet
Reports : Online & Offline

highlights

High-precision ECG acquisition with advanced ADC technology
Real-time ST segment and heart rate analysis
Smooth AC-driven treadmill for patient safety and comfort
Automated protocol execution and reporting
Reliable, cost-effective solution for cardiac diagnostics
Integration-ready with hospital workflows and reporting systems

in the box

TMT / ECG Acquisition Unit
Motorized Treadmill (AC-driven)
TMT & ECG Software
Trolley
Patient Cable
Disposable ECG Electrodes (1 pack)
TMT Graph Sheets (approx. 100 sheets)
Power cables & accessories
User manual & warranty card

Use Cases :

Cardiac stress testing (TMT / ETT)
Diagnosis of coronary artery disease (CAD)
Evaluation of exercise tolerance and cardiac fitness
Monitoring arrhythmias during exertion
Pre-operative cardiac assessment
Routine cardiovascular screening in hospitals & diagnostic centers

Key Features :

12-lead simultaneous ECG acquisition and display
PC-based cardiac workstation (resting + stress ECG)
High torque AC motor with digitally controlled drive system
Standard & customizable treadmill protocols (Bruce, Modified Bruce, etc.)
Duke Treadmill Score calculation for risk assessment
Real-time detection of arrhythmias and lead-off conditions
Event marking (chest pain, dyspnea, fatigue, angina, etc.)
User-configurable display and reporting formats
Smooth, noise-free elevation control
Emergency stop with alarm for safety
Anti-skid side strips and cushioned deck for patient comfort
Natural walking/running experience (no lag)
Optional upgrade to automatic NIBP module (SunTech)

Treadmill Specifications :

Speed Range : 0.1 – 9.3 mph
Elevation : 0 – 22%
Motor Power : 2 HP AC motor
Belt Type : Anti-skid conveyor belt
Communication : RS-232
Max User Capacity : Up to 250 kg
Walking Area : 1520 × 510 mm
Dimensions : 2180 × 815 × 1165 mm
Weight : ~145 kg

Warranty

Seller

AA MEDIE QUIPLearn More

Product Description

The RMS VEGA 204 AC is an advanced, PC-based cardiac stress testing system designed for accurate and non-invasive evaluation of heart performance under exercise conditions. It integrates resting and exercise ECG into a single workstation, enabling real-time monitoring and analysis of cardiac activit...
