HAMILTON-C1 Mechanical Ventilator

New

Specifications

Modes : Invasive, NIV (NIV-ST), ASV®, Volume & Pressure-based ventilation, Optional High Flow O₂ Therapy
Tidal Volume Range : 20 ml – 2000 ml (adult/pediatric); Neonatal upgrade: 2 ml – 300 ml
Patient Range : Neonatal (optional) to adult (3 kg – 200 kg)
Display : 8.4″ (214 mm) color TFT touchscreen, 640×480 px
Battery : Integrated, hot-swappable; ~4 hours runtime
Weight : ~4.9 kg (ventilator unit)
Dimensions : 310 × 210 × 245 mm (unit only)
Alarms & Monitoring : Extensive parameter monitoring + event log, optional mainstream/sidestream CO₂ and SpO₂
Peak Flow : >260 L/min with turbine
Oxygen Supply : Works with high & low-pressure O₂, connectors DISS or NIST (varies by region)
Connectivity : USB, RJ-45/Ethernet, nurse call, patient data interfaces
Sound Levels : ~43 dB(A) operation
Standards & Safety : IEC 60601-1, ISO 80601-2-12 compliance

highlights

Lung Protective Ventilation: ASV® mode prioritizes lung safety, comfort, and weaning support.
Full Parameter Visualization: Up to 24 parameters on a single screen for comprehensive patient assessment.
High Flow Oxygen & NIV: Optional modules extend therapy options without additional devices.
Patient-Adaptive Triggering: IntelliTrig® responds dynamically to patient effort and circuit changes.

Use Cases :

Intensive Care Units (ICU)
Emergency & Recovery Rooms
Intra-Hospital Transport
Pediatric & Neonatal Care
Long-Term Acute Care (LTAC)

Key Features :

Turbine-Driven Design: Independent of compressed air for maximum mobility and versatility.
Compact & Lightweight: Weighs ~4.9 kg — easy for transport and intra-hospital use.
Adaptive Support Ventilation (ASV®): Smart, lung-protective ventilation adapting to patient needs.
Multi-Mode Ventilation: Invasive, noninvasive (NIV), pressure/volume modes, and optional High Flow O₂ Therapy.
IntelliTrig® Leak Compensation: Advanced trigger sensitivity even with circuit leaks.
Integrated Monitoring & Connectivity: Capnography, SpO₂, alarms, and interface with EMRs.
Battery Backup: >4 hours operation with hot-swap capability.

Warranty

Seller

AA MEDIE QUIPLearn More

Product Description

The HAMILTON-C1 is a compact, yet powerful mechanical ventilator engineered for versatility and mobility across various critical care environments. Requiring minimal space, it seamlessly integrates invasive and noninvasive ventilation modes, alongside high flow oxygen therapy, making it an ideal com...
