Mindray SV600 ICU Ventilator

New

Specifications

Brand: Mindray
Model: SV600
Patient Age Groups: Neonatal, Pediatric, Adult
Mounting Type: ICU
Operating Type: Automatic
Display: 15.6-inch Full Color Touchscreen
Resolution: 1920x1080 pixels
Resolution: 1920x1080 pixels
Resolution: 1920x1080 pixels
Dimensions (HxWxD) (Including trolley and backup air supply): 1395mm x 530mm x 674mm
Weight (Including trolley and backup air supply): Approximately 45kg
Gas Flow (BTPS): ≥ 180 L/min
Backup Air Supply (Blower) Maximum Output Flow (BTPS): ≥ 200 L/min
Backup Air Supply (Blower) Maximum Output Pressure: ≥ 80 cmH₂O
Power Input Voltage: 100 to 240 V
Power Input Frequency: 50/60 Hz
Battery: One or Two built-in batteries

highlights

✔️ Comprehensive ventilation modes including invasive, non-invasive, and emergency (CPRV).
✔️ High-definition 15.6″ touchscreen with customizable UI and intuitive graphical guidelines.
✔️ Smart decision-support tools (AMV, IntelliCycle) to improve patient-ventilator synchrony.
✔️ Modular and expandable design — integrates future upgrades and monitoring modules.
✔️ Seamless connectivity with hospital networks for data interoperability.

in the box

Mindray SV600 ventilator unit
AC power cable & plugs
Backup air supply module
User manual / quick start guide
Basic breathing circuit components (may vary)
Filters and oxygen supply connectors
Optional modules (SpO₂/CO₂) (if purchased in bundle)

Use Cases :

Intensive Care Units (ICUs)
Emergency Departments
Post-operative and recovery areas
Post-operative and recovery areas

Key Features :

Suitable for Neonatal, Pediatric, and Adult patients
Automatic operation for streamlined use
Large 15.6-inch Full Color TFT Touchscreen display
High resolution display: 1920x1080 pixels
IEC 60601-1-2 compliance for Electromagnetic Compatibility (EMC)
Intended for intensive care situations and transport within healthcare facilities
Provides ventilation assistance and breathing support
Automatic switchover to alternative gas supply in case of failure
Backup air supply (Blower) with maximum output flow ≥ 200 L/min (BTPS)

Warranty

Seller

AA MEDIE QUIPLearn More

Product Description

The Mindray SV600 Ventilator is a high-end ICU ventilator engineered to provide comprehensive respiratory support across patient populations — neonatal, pediatric, and adult. It combines an intuitive, customizable user interface, powerful decision-support tools, and extensive ventilation modes to as...
